O1 Steel | 1.2510 | 9CrWMn | 95MnWCr1 | 90MnWCrV5 | SKS3 Oil-Hardening Cold Work Steel

O1 steel is a cold work steel belong to ASTM A681-1999 Steel Grade standard. O1 Special Steel China Supplier and factory Otai Special Steel Supply O1 Cold Work Tool steel in Round bar, Plate, Flat bar, Square, Forging Ring and others any shape. And provide cutting, sawing, milled, machining processing.

Supply Form of O1 Steel -ASTM A681 Alloy Cold Work Tool Steel
Supply Range of aisi O1 Tool Steel

O1 Steel Round Bar: diameter 5mm – 400mm

O1 Steel Plate: thickness 10 –500mm x width 200– 1400mm

O1 Steel Block: 210mm x 500-810mmAISI O1 Steel - ASTM A681 Grade oil hardening cold work tool steel

Chemical Composition of O1 Tool Steel Material
ASTM A681 C Si Mn P S Cr W V
O1/T31501  0.85～1.00  0.10～0.50 1.00～1.40  0.030 Max  0.030 Max 0.40～0.60  0.40～0.60  ≤0.30
DIN 17350 C Si Mn P S Cr W V
1.2510/95MnWCr1  0.90～1.05  0.15～0.35  1.00～1.20 0.035 Max 0.035 Max 0.50～0.70 0.50～0.70 0.05～0.15
GB/T 1299 C Si Mn P S Cr W V
9CrWMn 0.85～0.95 ≤0.40 0.90～1.20 0.030 Max 0.030 Max 0.50～0.80 0 0.50～0.80 ~
JIS G4404 C Si Mn P S Cr W V
SKS3 0.90～1.00 ≤0.35 0.90～1.20 0.030 Max 0.030 Max 0.50～1.00 0.50～1.00 ~
O1 tool Steel Equivalent and Related Speciation
USA German Japan China ISO
ASTM A681 DIN 17350 JIS G4404 GB/T 1299 ISO 4957
O1 1.2510 SKS3 9CrWMn X2009CrWMn



ASTM AISI O1 Tool Steel Material Mechanical Properties

Hardness, Rockwell C: 62 HRc, Density: 7.85kg/m3

Izod impact unnotched:

Melting point: 1421 ºC.

Forged of Cold Work O1 Steel material metal

Forged O1 tool steel at 800 – 1000 ºC. no forging when below 755 ºC.

Heat Treatment of SAE/AISI O1Steel
  • O1 Steel Annealing

Slowly heat to 700-800 ºC, keep enough time, ensure heat thoroughly. then cooling in furnace at 4-5 ºC per hour. After annealing, the hardness 217 HBS Max.

  • O1 tool Steel Hardening & Quenching

/ ℃ quenching temperature: 790 ~ 790

Quenching medium: oil

  • Tempering Of O1 Steel

/ ℃ tempering temperature: 150 ~ 150

After tempering hardness HRC: 62-57

Application of Sae AISI O1 tool Steel

O1 tool steel used for cold work tool products. Like forming dies , thread rolling dies, cutting knife, blanking dies, etc.

Quality Assured of Sae O1 Steel

Quality assured by Our ISO 9001:2008 quality management system. Our all O1 tool steel all had by SEP 1921-84 ultrasonic inspection (UT Test). Quality Grade: E/e, D/d, C/c.
