Cr12MoV Steel | SKD11 alloy steel

Description

Cr12MoV steel is a kind of ledeburite cold work tool steel which developed from Cr12 steel, as the added content of Mo, V, and decrease of C, Cr12MoV have the advantage of Higher hardenability, hardness, wear resistance and small heat treatment distortion. It’s regularly be used in manufacturing cold mold with a heavy load, bulk production, and complex shape. Due to Cr12MoV is ledeburite steel, so its toughness is greatly influenced by the carbide morphology and distribution.

Cr12MoV Steel, steel hardenability, quenching and tempering the hardness, wear resistance and strength than that of high Cr12. Cross section used in the manufacture large, complex shape, working under arduous conditions, with a variety of Die and tools, such as die punching, trimming mold, piping die, deep drawing steel mold, circular saws, standards, tools and gauges, thread rolling die and so on.

Cr12MoV Steel


Chemical composition% of Cr12MoV steel

C(%) Si(%) Mn(%) P(%) S(%) Cr(%) Ni(%) Mo(%) V(%) Cu(%)
1.45~1.70 ≤0.40 ≤0.40 ≤0.030 ≤0.030 11.00~12.50 ≤0.20 0.40~0.60 0.15~0.30 ≤0.30

Cr12MoV equivalents alloy steel

Steel Country Code C(%) V(%) Si(%) Mn(%) P(%) S(%) Cr(%)
SKD11 CNS 1.4-1.6 0.2-0.5 ≦0.4 ≦0.6 ≦0.03 ≦0.03 11.0-13.0
Cr12MoV GB 1.45-1.70 0.15-0.30 ≦0.4 ≦0.4 ≦0.03 ≦0.03 11.0-12.5
SKD11 JIS 1.4-1.6 0.2-0.5 ≦0.4 ≦0.6 ≦0.03 ≦0.03 11.0-13.0
X165Cr-MoV12 DIN 1.55-1.75 0.1-0.5 0.25-0.40 0.2-0.4 ≦0.03 ≦0.03 11.0-12.0

Cr12MoV steel Range of products

Product type Products Dimension Processes Deliver Status
Plates/Sheets Plates/Sheets 0.08-200mm(T)*W*L Forging, hot rolling, and cold rolling Annealed, Solution and Aging, Q+T, ACID-WASHED, Shot Blasting
Steel Bar Round Bar, Flat Bar, Square Bar Φ8-1200mm*L Forging, hot rolling and cold rolling, Cast Black, Rough Turning, Shot Blasting,
Coil/Strip Steel Coil/Steel Strip 0.03-16.0x1200mm Cold-Rolled&Hot-Rolled Annealed, Solution and Aging, Q+T, ACID-WASHED, Shot Blasting
Pipes/Tubes Seamless Pipes/Tubes, Welded Pipes/Tubes OD:6-219mm x WT:0.5-20.0mm Hot extrusion, Cold Drawn, Welded Annealed, Solution and Aging, Q+T, ACID-WASHED

Heat treatment of Cr12MoV Alloy Steel

spheroidizing annealing:860℃ X 2h furnace cooling to 750℃ and then furnace cooling to 500-550℃, remove out and air cooling

Quenched + tempered:1100℃ X 20min step quenching + 700℃ X 1h tempering,remove out and air cooling

Quenching:1030℃ X 40min oil quenching(800℃ preheating,vacuum 2.5 pa) Tempering: 250℃ X 1h


Application

Cold work dies steel, steel hardenability, quenching, and tempering hardness, wear resistance, strength is higher than Cr12. Used in the manufacture of various cold stamping dies and tools with large cross- sections, complex shapes and heavy working conditions, such as punching die, trimming die, piping dies, deep drawing dies, circular saw, standard tools, and gauges Thread rolling die, etc.


Contact

If you have any Cr12MoV Steel inquiries and questions for Price, Application, hot treatment, Please don’t hesitate to contact us.

Email: Jack@otaisteel.com

Tel:  +86-769- 23190193

Fax:  +86-769-88705839
