8620 hardness is an important indicator in the mechanical properties of 8620 steel. Understanding the 8620 hardness range that can help us to better understand the properties of 8620 steel and the application fields. The following is the details about 8620 hardness.
8620 is a low alloy case hardening steel which is supplied to American standard SAE 8620 and AISI 8620. 8620 can be carburized, which will achieve a tough core with a hard wear-resistant case. 8620 provides a combination of toughness and wear resistance. 8620 is supplied in either the as-rolled or annealed condition for subsequent case hardening.
So what is 8620 mechanical properties and 8620 hardness?
The most widely used alloy case-hardening steel, which may be carburized and hardened to produce a hard wear-resistant case combined with the core strength of the order of 125,000 psi (862 N/mm2). Uniform case depth, hardness and wear properties with minimum distortion are characteristics of this grade. The steel may also be used, not carburized, in a variety of general applications where a ’20’ carbon alloy is desirable.
The mechanical properties of AISI 8620 alloy steel:
Properties | Metric | Imperial |
Tensile strength | 530 MPa | 76900 psi |
Yield strength | 385 MPa | 55800 psi |
Elastic modulus | 190-210 GPa | 27557-30458 ksi |
Bulk modulus (typical for steel) | 140 GPa | 20300 ksi |
Shear modulus (typical for steel) | 80 GPa | 11600 ksi |
Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
Izod Impact | 115 J | 84.8 ft.lb |
Hardness, Brinell | 149 | 149 |
Hardness, Knoop (converted from Brinell hardness) | 169 | 169 |
Hardness, Rockwell B (converted from Brinell hardness) | 80 | 80 |
Hardness, Vickers (converted from Brinell hardness) | 155 | 155 |
8620 Delivery status
Delivery in normalizing, annealing or high tempering or without heat treatment according to your requirements.
