AISI 1020 Steel is low hardenability and low tensile carbon steel carbon steel. And its Brinell hardness of 119 – 235 and tensile strength of 410-790 MPa. It is normally used in turned and polished or cold drawn condition. AISI 1020 steel ( JIS S20C steel) is resistant to induction hardening or flame hardening due to its low carbon content. What’s more, it will not response to nitriding because its lack of alloy metal element. Core strength will remain as it has been supplied for all the sections.
To meet the enhance weldability or machinability properties propose, AISI 1020 steel ( DIN 1.1151 steel) can be largely utilized in all industrial sectors. It can be cold drawn or turned and polished finish property to fit all kinds of industryies mechnical request.
AISI / SAE / ASTM 1020 steel Related Specifications ASTM A29/29M-1999
Chemical composition
1. Carbon, C: 0.17 – 0.230 %
2. Iron, Fe: 99.08 – 99.53 %
3. Manganese, Mn: 0.30 – 0.60 %
4. Phosphorous, P: ≤ 0.040 %
5. Sulfur, S: ≤ 0.050 %
Equivalent Of DIN 1.1151 Carbon Steel | flat steel bar
USA | Germany | China | Japan | France | England | Italy | Poland | ISO | Austria | Sweden | Spain |
ASTM/AISI/UNS/SAE | DIN,WNr | GB | JIS | AFNOR | BS | UNI | PN | ISO | ONORM | SS | UNE |
1020/ G10200 | C22E/Ck22/1.1151 | 20 | S20C | C22E / XC18 | C22E/ 070M20 | 1435 | |||||
AISI 1020 steel Form of Supply
ASTM 1020 mild steel, we can supply the round bar, flat bar, plate, hexagonal and square block. Diameters can be saw to your required lengths as one offs or multiple cut pieces. Rectangular pieces can be saw from flat bar or plate to your specific sizes. Ground tool steel bar can be supply, providing a quality precision finish bar to tight tolerances.
JIS S20C steel Applications
ASTM 1020 mild steel is suitable for making cars, tractors and general machinery small and medium-sized carburizing and carbonitriding and other parts, such as car hand brake shoe, fork lever shaft, transmission speed, transmission driven gear and the tractor on the camshaft, hanging equalizer axle, equalizer, inner and outer bushing, etc.; AISI 1020 Steel In the condition of hot rolling or normalizing used in the manufacture of force is not big, but all kinds of high toughness requirement of mechanical parts;In medium and heavy machinery industry, such as forging or suppression of rod, shackle, leverage, sleeve, fixture, etc. JIS S20C Steel; In steam turbine and boiler manufacturing for more pressure or less 6N/㎡, the temperature of 450 ℃ or less corrupt media work of pipes, flanges, header, and various kinds of fasteners; On the railway and locomotive vehicles used in the manufacture of the crosshead and piston castings.
AISI 1020 Mild steel Regular size and Tolerance
1.1151 Steel round bar: Diameter Ø 5mm – 3000mm
S20C Steel plate: Thickness 5mm – 3000mm x Width 100mm – 3500mm
1020 Steel Hexagonal bar: Hex 5mm – 105mm
Diameter small than 90mm can use cold drawn make. we can provide cold drawn, cold rolled, hot rolled, forged Grade Aisi 1020 mild steel material
Others have not specified size, pls contact our experienced sales team.
AISI 1020 steel Processing
1020 mild steel round bar and flat sections can be cut to your required sizes. ASTM 1020 steel ground bar can also be supplied, providing a high quality tool steel precision ground tool steel bar to your required tolerances. 1020 steel is also available as Ground Flat Stock / Gauge Plate, in standard and nonstandard sizes.
